HX-407 Commercial Grade Handheld UHF
Yaesu Standard Horizon
HX-407 Commercial Grade Handheld UHF
HX407 Commercial Grade Handheld UHF
- Submersible IPX8 / 1.5M (4.92Ft) for 30 minutes
- Selectable 5 or 1 Watt transmit power output
- 40 Programmable UHF Channels
- Battery life indicator on the display
- Supplied with a 2300mAh Li-Ion battery, 110 VAC and 12 VDC 3-hour rapid chargers
- Programmable Channel Names
- Built in voice scrambler
- Optional FBA-42 (6 x AA) Alkaline battery tray available
- Preset key used to recall up to 10 favorite channels
- Optional speaker microphones and headsets available
|
FEATURES: |
|
40 Programable UHF Channels
Up to 40 channels can be programmed into the HX407 using the programming software provided by your Standard Horizon dealer.Battery Life Indicator The display shows a battery bar graph guage to inform the charge left in the Lithium-ion battery.Lithium Ion Battery and Rapid Charger The HX407 is supplied with a whopping 2300 mAh Lithium-Ion battery that will keep you talking for about 17 hours.Programmable Channel Names The HX407 is supplied preloaded with a description of the use of each of the Marine channels (16-Distress, 22A-USCG, 71-Pleasure). The channel names may be customized by the user to easily understand the use of each channel.Built in Voice Scrambler For secure communications, the HX407 has a built in scrambler which can be turned on and off for secure or open communications on the desired operating channel |
SPECIFICATIONS
Performance specifications are nominal, unless otherwise indicated, and are
subject to change without notice.
GENERAL
Frequency Ranges: 406.100 MHz to 470.000 MHz
Channel Spacing: 25 kHz / 12.5 kHz
Frequency Stability: ±2.5 ppm
Emission Type: 16K0G3E / 11K0G3E
Antenna Impedance: 50 Ω
Supply Voltage: 7.4V DC, Negative Ground (Battery Terminal)
Operating Temperature: -22 °F to +140 °F (-30 °C to +60 °C)
Battery Type and capacity: Lithium-Ion, 2300 mAh (Rated) 2400 mAh (Typ)
Waterproof Rating: JIS-8 / IPX8 (1.5 m or 4.92 feet for 30 minutes)
TRANSMITTER
RF Power Output: 5 W / 1 W (@7.4 V )
Maximum Deviation: ±5.0 kHz (Wide) / ±2.5 kHz (Narrow)
Hum and Noise Ratio: More than 40 dB
Spurious Emission: Less than 0.25 uW
RECEIVER
Adjacent Channel Selectivity: More than 70 dB (Wide), More than 60 dB (Narrow)
Intermodulation: More than 68 dB
Spurious Response Rejection: More than 70 dB
Hum and Noise Ratio: More than 40 dB
Max imum Audio Output Power: 700 mW @16 Ω for 10 % THD (@7.4 V)
AF Output (External SP): 300 mW @8 Ω for 10 % THD (@7.4 V)
Spurious Emission: Less than 2 nW
Measured in accordance with TIA/EIA-603.
